Maple SystemsDistribuidor autorizado
OMI6812BPHEB
With a solid state platform and fanless cooling system, this UL-certified IPC is ideal forWith a solid state platform and fanless cooling system, this UL-certified IPC is ideal for industrial applications. The OMI6812BPHEB is a rugged 12.1” extended temperature ( -20~60°C) , 1000 nits -high bright display, optically bonded capacitive touchscreen industrial computer designed to meet strict industry standards.
CantidadPrecio y entrega: Por cotización
¿Necesitas un equivalente u otra presentación? Llámanos al +52 (868) 817-7915 o escribe a ventas@gugo.com.mx.
- 800 x 600 Resolution
- High Brightness-1000 nits, Optically Bonded Capacitive Touchscreen
- Intel ® Pentium Apollo Lake N4200 Quad-Core 1.1 GHz Processor
- Microsoft Windows ® 10 IoT Ent Embedded 64-bit
- -20~60°C Operating Temperature
- Aluminum Enclosure, VESA or Panel Mount
- IP66/NEMA4
- Optional Wi-Fi Upgrade
Hoja de datosmaplesystems.comDibujo 2D (CAD)maplesystems.comModelo 3D (CAD)maplesystems.comFicha en maplesystems.commaplesystems.com
Sistema
- CPU
- Intel® Pentium™ Apollo Lake™ N4200 Quad-Core 1.1GHz Processor
- Memory (RAM)
- Onboard DDR3L 4 GB 1600 MHz
- System Chipset
- SoC
- Solid State Drive Type
- 1 x 2.5” SATA III, MLC
- Solid State Drive Capacity
- 64, 128, 256, 512 GB, 1TB SSD
Puertos de E/S
- Power
- 3-pin connector header, DC power input
- Ethernet/LAN
- 2 x GbE RJ-45
- Audio Output
- 1 x 3.5 mm line out
- SD Card Slot
- 1 x internal micro Secure Digital memory card socket, up to 32 GB
- HDMI Port
- No
- Remote Power Switch
- 2-pin connector header
- Display Output
- No
- USB 3.0 Type A
- 2
- Serial Ports
- 2
- Serial Options
- 1 x RS-232/422/485 DE-9P, COM1 (default RS-232), 1 x RS-232 DE-9P, COM2
- Expansion Option
- Optional Wi-Fi kit (IEEE 802.11a/b/g/n/ac card and antenna)
Pantalla
- Display Size
- 12.1” SVGA TFT LCD
- Resolution
- 800 x 600
- Luminance (cd/m^2)
- 1000
- Contrast Ratio
- 1000:1
- Backlight Lifetime (hrs)
- 50,000+
- Colors
- 16.7 M
- View Angle (H° V°)
- 176/176
Pantalla táctil
- Touch Interface
- USB
- Light Transmission
- 90+%
- Optical Bonding
- Yes
- Touch Screen Type
- Projected Capacitive
Eléctrico
- Input Power
- 42.4 W
- Input Voltage
- 9~36 VDC
- Input Current
- 1.18-4.71 A
Mecánico
- Enclosure Material
- Silver aluminum front bezel and chassis
- Dimensions WxHxD
- 12.56 x 9.65 x 2.03” [319 x 245 x 51.7 mm]
- Panel Cutout (inches) [mm]
- 11.93 x 9.02 [303 x 229 ]
- Weight
- ~ 6.2 lbs [2.8 kg]
- Mounting
- Panel mounting, VESA 100 x 100 mm
Ambiental
- Operating Temperature
- -4~140°F [-20~60°C]
- Storage Temperature
- -22~158°F [-30~70°C]
- Relative Humidity
- 10 to 90% @ 40°C, non-condensing
Certificaciones
- NEMA Rating
- NEMA 4 when panel mounted
- IP Rating
- IP66
- CE
- Yes
- UL
- Yes
- ATEX
- No
- RoHS
- Yes
- FCC
- FCC Class A
Datos del producto
- Marca
- Maple Systems
- Número de parte
- OMI6812BPHEB
- Línea
- High-Brightness PCs · Extended Temp. PCs · Industrial Panel PCs
- Categoría
- PC y monitores industriales
- Precio y entrega
- Por cotización
