OMI6810BPHEB
The robust OMI6810BPHEB is a 10.1” extended temperature ( -20~60°C ), 1000 nits display, oThe robust OMI6810BPHEB is a 10.1” extended temperature ( -20~60°C ), 1000 nits display, optically bonded capacitive touchscreen, industrial computer designed to meets strict industry standards. With a solid state platform and fanless cooling system, this UL-certified IPC is ideal for most applications.
CantidadPrecio y entrega: Por cotización
¿Necesitas un equivalente u otra presentación? Llámanos al +52 (868) 817-7915 o escribe a ventas@gugo.com.mx.
- 1280 x 800 Resolution
- High Brightness-1000 nits, Optically Bonded Capacitive Touchscreen
- Intel ® Pentium Apollo Lake N4200 Quad-Core 1.1 GHz Processor
- Microsoft Windows ® 10 IoT
- -20~60°C Operating Temperature
- Aluminum Enclosure, VESA or Panel Mount
- IP66/NEMA 4 when panel mounted
- Optional Wi-Fi Upgrade
Hoja de datosmaplesystems.comDibujo 2D (CAD)maplesystems.comModelo 3D (CAD)maplesystems.comFicha en maplesystems.commaplesystems.com
Sistema
- CPU
- Intel® Pentium™ Apollo Lake™ N4200 Quad-Core 1.1GHz Processor
- Memory (RAM)
- Onboard DDR3L 4 GB 1600 MHz
- System Chipset
- SoC
- Solid State Drive Type
- 1 x 2.5” SATA III, MLC
- Solid State Drive Capacity
- 64, 128, 256, 512 GB, 1TB SSD
Puertos de E/S
- Power
- 3-pin connector header, DC power input
- Ethernet/LAN
- 2 x GbE RJ-45
- Audio Output
- 1 x 3.5 mm line out
- SD Card Slot
- 1 x internal micro Secure Digital memory card socket, up to 32 GB
- HDMI Port
- No
- Remote Power Switch
- 2-pin connector header
- Display Output
- No
- USB 3.0 Type A
- 2
- Serial Ports
- 2
- Serial Options
- 1 x RS-232/422/485 DE-9P, COM1 (default RS-232), 1 x RS-232 DE-9P, COM2
- Expansion Option
- Optional Wi-Fi kit (IEEE 802.11a/b/g/n/ac card and antenna)
Pantalla
- Display Size
- 10.1” WXGA TFT LCD
- Resolution
- 1280 x 800
- Luminance (cd/m^2)
- 1000
- Contrast Ratio
- 1300:1
- Backlight Lifetime (hrs)
- 50,000+
- Colors
- 16.2 M
- View Angle (H° V°)
- 170/170
Pantalla táctil
- Touch Interface
- USB
- Light Transmission
- 90+%
- Optical Bonding
- Yes
- Touch Screen Type
- Projected Capacitive
Eléctrico
- Input Power
- 26.7 W
- Input Voltage
- 9~36 VDC
- Input Current
- 0.74-2.97 A
Mecánico
- Enclosure Material
- Silver aluminum front bezel and chassis
- Dimensions WxHxD
- 11.22 x 7.44 x 1.93” [285 x 189 x 48.9 mm]
- Panel Cutout (inches) [mm]
- 10.71 x 6.93 [272 x 176 ]
- Weight
- ~ 4.4 lbs. [2.0 kg]
- Mounting
- Panel mounting, VESA 100 x 100 mm
Ambiental
- Operating Temperature
- -4~140°F [-20~60°C]
- Storage Temperature
- -22~158°F [-30~70°C]
- Relative Humidity
- 10 to 90% @ 40°C, non-condensing
Certificaciones
- NEMA Rating
- NEMA 4 when panel mounted
- IP Rating
- IP66
- CE
- Yes
- UL
- Yes
- ATEX
- No
- RoHS
- Yes
- FCC
- FCC Class A
Datos del producto
- Marca
- Maple Systems
- Número de parte
- OMI6810BPHEB
- Línea
- High-Brightness PCs · Extended Temp. PCs · Industrial Panel PCs
- Categoría
- PC y monitores industriales
- Precio y entrega
- Por cotización
