Maple SystemsDistribuidor autorizado
EDGEEH-01-N-231
Windows-based Embedded HMI/Win 10 IoT/Win 11 IoT 1 Runtime License Included 1,500 Tags, 1 Windows-based Embedded HMI/Win 10 IoT/Win 11 IoT 1 Runtime License Included 1,500 Tags, 1 Thin Client Softkey Only, Hardkey Sold Separately Compare Windows Embedded Version with Windows Full Version and Linux or Non-Windows Version
CantidadPrecio y entrega: Por cotización
¿Necesitas un equivalente u otra presentación? Llámanos al +52 (868) 817-7915 o escribe a ventas@gugo.com.mx.
- Windows-based Embedded HMI/Win 10 IoT/Win 11 IoT
- 1 Runtime License Included
- 1,500 Tags, 1 Thin Client
- Softkey Only, Hardkey Sold Separately
Licensing
- License Type
- Windows Embedded Standard (Win 10 IoT/Win 11 IoT) – Runtime Only
- Number of Tags
- 1,500
- Number of Supported Thin Clients
- Unlimited Learn More Number of Supported Thin Clients: Unlimited Limited by license and external and physical constraints (hardware and operating system).
- License Server
- Not Supported
- USB Hardkey
- Supported with Limitations Learn More USB Hardkey: Supported with Limitations The hardware from the WiBu manufacturer is supported by all Runtime Editions (excluding IoT View)
Operating System
- Windows Server 2022
- Not Supported
- Windows Server 2019
- Not Supported
- Windows Server 2016
- Not Supported
- Windows 11
- Not Supported
- Windows 10
- Not Supported
- Windows 11 IoT Enterprise
- Supported
- Windows 10 IoT Enterprise (LTSC/LTSB)
- Supported
- Linux (x86/arm)
- Not Supported
System Requirements
- Minimum Free Storage Memory Needed
- 128MB
- Minimum Free RAM Memory Needed
- 64MB
General
- Run applications designed with the same IDE
- Supported
- Run as a service
- Not Supported
- Email (SMTP Client)
- Supported
- Create tags programmatically during the runtime
- Not Supported
- Create screens programmatically during the runtime
- Not Supported
- Create reports in PDF format
- Not Supported
- Built-in functions
- Supported with limitations Learn More Built-in functions: Supported with limitations The vast majority of the built-in functions are supported by all Runtime Editions. However, specific functions are Not supported on specific platforms. The complete reference is available in the Technical reference manual at "Appendix: Built-in Scripting Language > List of available functions"
- Tag integration (Shared Tags)
- Supported
Global
- Project Tags, System Tags, Classes and Arrays
- Supported
- Security system
- Supported
- Procedures
- Supported
- Event logger
- Supported
- Translation
- Supported
Tasks
- Alarms
- Supported
- Trend Logger
- Supported
- Native Integration with AVEVA System Platform
- Supported
- Native Integration with AVEVA Historian (on premise)
- Supported
- Native Integration with AVEVA Insight (on the cloud)
- Supported
- Recipes
- Supported
- Reports
- Supported
- ODBC
- Supported with Limitations Learn More ODBC: Supported with Limitations Even though the ODBC worksheets (legacy) are not supported, the Database/ERP worksheets are supported.
- Math
- Supported
- Script
- Supported
- Scheduler
- Supported
- Database/ERP
- Supported
- Azure IoT Hub
- Not Supported
Comunicación
- Drivers
- Supported with Limitations Learn More Drivers: Supported with Limitations The vast majority of the native communication drivers are supported by many runtime editions. However, specific native drivers are not supported on specific platforms. The complete reference is available through the actual product (Project Explorer > Comm > Drivers > Add/Remove Drivers). Moreover, IoT View supports main driver sheets only.
- OPC DA 2.5 Client
- Supported Learn More OPC DA 2.5 Client: Supported Starting with this release, OPC DA Client (legacy) is disabled by default in new projects, though projects created in previous versions that use OPC DA Client (legacy) will function.
- OPC DA 2.5 Server
- Supported
- OPC XML/DA Client
- Not Supported
- OPC UA Client
- Supported
- OPC UA Server
- Supported
- TCP/IP Client
- Supported
- TCP/IP Server
- Supported
- Mobile Access Runtime
- Supported
- OPC HDA Server
- Not Supported
Graphical Interface
- Screens
- Supported
- Screen Group
- Supported
- Graphic Script
- Supported
- Local Viewer
- Supported
- Server for SMA Thin Clients (HTML5)
- Supported
- Server for Secure Viewer Thin Clients
- Supported
- Server for Web Thin Clients
- Supported
- Support for CGI Web Servers
- Supported (8,0)
- Screen Scripts
- Supported
- Shapes
- Supported
- Active Objects
- Supported
- Data Objects (Alarm/Event, Trend, Grid)
- Supported
- Libraries – Project Symbols
- Supported
- Libraries – Linked Pictures
- Supported
- Libraries – .NET Controls
- Not Supported
- Libraries – ActiveX Controls
- Supported
- Libraries – Custom Widgets
- Supported (8.0+SP1)
- Auto Screen Scaling
- Supported with Limitations Learn More Auto Screen Scaling: Supported with Limitations The screens can be converted to a different resolution by using the command "Home > Convert resolution"
- Fill Effects
- Supported with Limitations Learn More Fill Effects: Supported with Limitations Fill effects are supported for rectangle objects.
- Background Picture
- Supported with Limitationis Learn More Background Picture: Supported with Limitationis The following formats are supported: BMP, JPG, and PNG, as long as the image of the device supports these formats as well.
- Ellipse Style Types
- Supported with Limitations Learn More Ellipse Style Types: Supported with Limitations The style type Ellipse is supported, but the style types Arc, Chord, and Ring are not supported.
- Hint (Tooltip)
- Supported with Limitations Learn More Hint (Tooltip): Supported with Limitations The Hint field will update the Hint System Tag. The graphical tooltip will not be automatically displayed on Compact HMI runtime nor SMA Thin Clients.
- Command Events
- Supported with Limitations Learn More Command Events: Supported with Limitations The Command events "On Down", "While Down", and "On Up" are supported. The remaining command events are not supported.
- Rotation Animation
- Supported with Limitations Learn More Rotation Animation: Supported with Limitations The Rotation Animation is supported for closed polygons, but not for pictures.
- Trend Control > Export to file
- Not Supported
- Trend Control > Points > Pen Style > Fill
- Not Supported
- Enhanced Graphics (Anti-Aliasing, Gradual Transparency)
- Not Supported
- Multi-Touch Gestures
- Supported with Limitations Learn More Multi-Touch Gestures: Supported with Limitations Compact HMI does not support "Zoom and Pan gestures on project screens" and "Gestures with Rotation Animation".
- Industrial Graphics
- Not Supported
Datos del producto
- Marca
- Maple Systems
- Número de parte
- EDGEEH-01-N-231
- Línea
- AVEVA™ Edge License · AVEVA™ · Software
- Categoría
- Software y licencias
- Precio y entrega
- Por cotización
