RSR30-D12-A1-24-020-1
Slimline Interface Relay, 12V DC, AC Load - 2A / 240VRSR30 Slimline Interface Relay, 12V DC, AC Load - 2A / 240V Standard Features Optically isolated Low on-state resistance Low input power consumption TTL and CMOS compatible RC networks (V AC) MOSFET output thyristor (V DC) Applications: household appliances, temperature control system, industrial automatic control, light system, office appliances, factory appliances Mounting: relays RSR30 are designed for direct PCB mounting, single in line package DATA Sheet Link
CantidadPrecio y entrega: Por cotización
¿Necesitas un equivalente u otra presentación? Llámanos al +52 (868) 817-7915 o escribe a ventas@gugo.com.mx.
Especificaciones técnicas
- Industrial Relays - Dimensions (L x W x H)
- 28 x 5 x 15 mm
- Industrial Relays - Weight
- 4 g
- Industrial Relays - Storage Temperature
- -40...+100 °C
- Industrial Relays - Operating Temperature
- -20...+80 °C rated value: +55 °C
- Industrial Relays - Nominal Voltage V DC
- 12
- Industrial Relays - Control voltage range V DC
- 7...20
- Industrial Relays - Max. control current mA
- 10
- Industrial Relays - Release voltage V DC
- 1
- Industrial Relays - Input resistance kΩ
- 1.07
- Industrial Relays - Nominal load current
- 1 A AC
- Industrial Relays - Max. load current
- 2 A AC
- Industrial Relays - Nominal load voltage
- rest condition: 240 V AC
- Industrial Relays - Load voltage range
- 12...280 V AC
- Industrial Relays - Non-repetitive peak voltage
- rest condition: 600 V AC
- Industrial Relays - Non-repetitive surge current
- operating state: 80 A
- Industrial Relays - Max. on-state voltage drop
- operating state: 1.2 V
- Industrial Relays - Min. load current
- operating state: 50 mA
- Industrial Relays - Off-state dV/dt
- max. allowable rate of voltage rise: 500 V/μs
- Industrial Relays - Operating frequency range
- 47...400 Hz
- Industrial Relays - RC Snubber
- 10 nF, 100 Ω
- Industrial Relays - Output circuit switching moment
- R - instantaneous switching of the output circuit
- Industrial Relays - Max. turn-on time
- 100 μs at rated voltage
- Industrial Relays - Max. turn-off time
- 1/2 cycle + 1 ms at rated voltage
- Industrial Relays - Insulation dielectric strength
- Between input and output: 4000 V AC 1 minute
- Industrial Relays - Max. solder bath temperature
- 220 °C 10 s
- Industrial Relays - Max. off-state leakage current (rest condition)
- 1.5 mA
- Industrial Relays - Relay Type
- RSR30
Datos del producto
- Marca
- Altech
- Número de parte
- RSR30-D12-A1-24-020-1
- Categoría
- Relevadores de estado sólido
