RM699BV-3211-85-1048
Slimline Interface Relay, 0.05A, SPDT DC CoilRM699B SPDT Gold Plated Contacts DC Coil / 0.05A Rated Current, Slimline Interface Relay RM699B for PCB Mounting or Plug-in Sockets Standard Features • Cover width only 5.0 mm• Sealed for soldering and cleaning• Applications: for PLC's, industrial machinery, time relays, counters, temperature adjusters, measurement instruments, office equipment, etc. DATA Sheet Link
CantidadPrecio y entrega: Por cotización
¿Necesitas un equivalente u otra presentación? Llámanos al +52 (868) 817-7915 o escribe a ventas@gugo.com.mx.
Especificaciones técnicas
- Industrial Relays - Coil Voltage (V)
- 48
- Industrial Relays - Coil Type
- DC
- Industrial Relays - Coil resistance at 20 °C in Ω
- 10600
- Industrial Relays - Coil operating range max. (at 55°C)
- 72
- Industrial Relays - Coil operating range min. (at 20°C)
- 36
- Industrial Relays - Number and type of contacts
- SPDT
- Industrial Relays - Contact material
- AgSnO2 / Au3µm
- Industrial Relays - Rated / max. switching voltage AC
- 30 V AC / 36 V DC
- Industrial Relays - Min. switching voltage
- 5 V
- Industrial Relays - Rated load (capacity) AC1
- 0.05 A / 30V AC
- Industrial Relays - Rated load (capacity) DC1
- 0.05 A / 36 V DC
- Industrial Relays - Min. switching current
- 100 mA
- Industrial Relays - Max. inrush current
- 0.1 A 20 ms
- Industrial Relays - Rated current
- 0.05A
- Industrial Relays - Max. breaking capacity AC1
- 1.2 VA
- Industrial Relays - Min. breaking capacity
- 0.05 W
- Industrial Relays - Contact resistance
- ≤ 30 mΩ 10 mA. 5 V
- Industrial Relays - Max. operating frequency at rated load AC1
- 360 cycles/hour
- Industrial Relays - Max. operating frequency - No load
- 72000 cycles/hour
- Industrial Relays - Must release voltage
- DC: ≥ 0.05 Un
- Industrial Relays - Rated power consumption
- DC: 0.17 W 5 ... 24 V; 0.217 W 48. 60 V
- Industrial Relays - Insulation rated voltage
- 250 V AC
- Industrial Relays - Overvoltage category
- III
- Industrial Relays - Dielectric strength between coil and contacts
- 4000 V AC type of insulation: reinforced
- Industrial Relays - Dielectric strength contact clearance
- 1000 V AC type of clearance: micro-disconnection
- Industrial Relays - Contact - Coil distance Clearance
- ≥ 6 mm
- Industrial Relays - Contact - Coil distance Creepage
- ≥ 8 mm
- Industrial Relays - Operating / release time (Typical)
- 8 ms / 4 ms
- Industrial Relays - Electrical life- resistive AC1
- the SPST (1 NO) and SPST (1 NC) contact loaded (bilateral load): see data sheet, the SPST (1 NO) contact loaded: greater than 3 x 104; 6 A. 250 V AC
- Industrial Relays - Mechanical life (cycles)
- greater than 10⁷
- Industrial Relays - Dimensions (L x W x H)
- 28 x 5 x 15 mm
- Industrial Relays - Weight
- 6 g
- Industrial Relays - Storage Temperature
- -40...+85 °C
- Industrial Relays - Operating Temperature
- -40...+85 °C
- Industrial Relays - Protection Category
- IP 64 PN-EN 60529
- Industrial Relays - Environmental Protection
- RTIII PN-EN 116000-3
- Industrial Relays - Shock resistance (NO/NC)
- 5 g
- Industrial Relays - Vibration resistance
- 5 g 10...55 Hz
- Industrial Relays - Solder bath temperature
- max. 260 °C
- Industrial Relays - Soldering time
- max. 5 s
- Industrial Relays - Relay Type
- RM699B
Datos del producto
- Marca
- Altech
- Número de parte
- RM699BV-3211-85-1048
- Categoría
- Relevadores de estado sólido
- Precio y entrega
- Por cotización
