RM50-3011-85-1018
SPDT, 12A Miniature Electromagnetic RelayR50 SPDT DC Coil, Miniature Electromagnetic Relay Standard Features Small dimensions Switching current up to 10 A / 15 A The plastics applied provide for the operation of the relays at high temperature and in chemical environment Sealed, for soldering Applications: for household equipment, office machines, audio equipment, coffee machines, control devices, etc. Recognitions, certifications, directives: RoHS DATA Sheet Link
CantidadPrecio y entrega: Por cotización
¿Necesitas un equivalente u otra presentación? Llámanos al +52 (868) 817-7915 o escribe a ventas@gugo.com.mx.
Especificaciones técnicas
- Industrial Relays - Coil Voltage (V)
- 18
- Industrial Relays - Coil Type
- DC
- Industrial Relays - Coil resistance at 20 °C in Ω
- 900
- Industrial Relays - Coil operating range max. (at 55°C)
- 23.4
- Industrial Relays - Coil operating range min. (at 20°C)
- 13.5
- Industrial Relays - Number and type of contacts
- SPDT
- Industrial Relays - Contact material
- AgSnO2
- Industrial Relays - Rated / max. switching voltage AC
- 240 V / 277 V
- Industrial Relays - Min. switching voltage
- 5 V
- Industrial Relays - Rated load (capacity) AC1
- 10 A / 240 V AC
- Industrial Relays - Rated load (capacity) DC1
- 15 A / 24 V DC
- Industrial Relays - Min. switching current
- 15 mA
- Industrial Relays - Rated current
- 12A
- Industrial Relays - Max. breaking capacity AC1
- 3000 VA
- Industrial Relays - Min. breaking capacity
- 0.75 W
- Industrial Relays - Contact resistance
- ≤ 100 mΩ
- Industrial Relays - Must release voltage
- DC: ≥ 0.05 Un
- Industrial Relays - Rated power consumption
- DC: 0.36 W 3 ... 24 V; 0.45 W 48 V
- Industrial Relays - Dielectric strength between coil and contacts
- 1000 V AC type of insulation: basic
- Industrial Relays - Dielectric strength contact clearance
- 500 V AC type of clearance: micro-disconnection
- Industrial Relays - Contact - Coil distance Clearance
- ≥ 1.9 mm
- Industrial Relays - Contact - Coil distance Creepage
- ≥ 1.9 mm
- Industrial Relays - Operating / release time (Typical)
- 10 ms / 5 ms
- Industrial Relays - Electrical life- resistive AC1
- 1200 cycles/hour: greater than 10^5; 7 A, 250 V AC and greater than 3 x 104; 12 A, 250 V AC
- Industrial Relays - Electrical life- resistive DC1
- 1200 cycles/hour: greater than 5 x 10^4; 15 A, 24 V DC
- Industrial Relays - Mechanical life (cycles)
- 18 000 cycles/hour: greater than 10^7
- Industrial Relays - Dimensions (L x W x H)
- 19 x 15.4 x 15.5 mm
- Industrial Relays - Weight
- 11 g
- Industrial Relays - Operating Temperature
- -30...+55 °C
- Industrial Relays - Protection Category
- IP 64 PN-EN 60529
- Industrial Relays - Shock resistance (NO/NC)
- 10 g
- Industrial Relays - Vibration resistance
- 1.5 mm DA (constant amplitude) 10...55 Hz
- Industrial Relays - Solder bath temperature
- max. 235 °C
- Industrial Relays - Soldering time
- max. 5 s
- Industrial Relays - Relay Type
- RM50
Datos del producto
- Marca
- Altech
- Número de parte
- RM50-3011-85-1018
- Categoría
- Medición y monitoreo
