R2M-2012-23-1012
DPDT, 5A Industrial Electromagnetic RelayR2M DPDT DC coil, Industrial Electromagnetic Relay Standard Features: Relays of general application For plug-in sockets, 35 mm rail mount or on panel mounting Cadmium-free contacts R2M and RUC also for PCB and soldering connections AC and DC coils available DATA Sheet Link
CantidadPrecio y entrega: Por cotización
¿Necesitas un equivalente u otra presentación? Llámanos al +52 (868) 817-7915 o escribe a ventas@gugo.com.mx.
Especificaciones técnicas
- Industrial Relays - Coil Voltage (V)
- 12
- Industrial Relays - Coil Type
- DC
- Industrial Relays - Coil resistance at 20 °C in Ω
- 188
- Industrial Relays - Coil operating range max. (at 55°C)
- 13.2
- Industrial Relays - Coil operating range min. (at 20°C)
- 9.6
- Industrial Relays - Number and type of contacts
- DPDT
- Industrial Relays - Contact material
- AgNi
- Industrial Relays - Rated / max. switching voltage AC
- 250 V / 250 V
- Industrial Relays - Min. switching voltage
- 5 V
- Industrial Relays - Rated load (capacity) AC1
- 5 A / 250 V AC
- Industrial Relays - Rated load (capacity) DC1
- 5 A / 24 V DC
- Industrial Relays - Min. switching current
- 5 mA
- Industrial Relays - Rated current
- 5A
- Industrial Relays - Max. breaking capacity AC1
- 1250 VA
- Industrial Relays - Min. breaking capacity
- 0.3 W
- Industrial Relays - Contact resistance
- ≤ 100 mΩ
- Industrial Relays - Max. operating frequency at rated load AC1
- 1200 cycles/hour
- Industrial Relays - Max. operating frequency - No load
- 36000 cycles/hour
- Industrial Relays - Rated voltage 50/60 Hz
- AC: 6 ... 240 V, DC: 6 ... 110 V
- Industrial Relays - Must release voltage
- ≥ 0.05 Un
- Industrial Relays - Rated power consumption
- AC: 1.2 VA, DC: 0.9 W
- Industrial Relays - Insulation rated voltage
- 250 V AC
- Industrial Relays - Rated surge voltage
- 2500 V 1.2 / 50 µs
- Industrial Relays - Overvoltage category
- II
- Industrial Relays - Insulation pollution degree
- 3
- Industrial Relays - Dielectric strength between coil and contacts
- 2000 V AC type of insulation: basic
- Industrial Relays - Dielectric strength contact clearance
- 1000 V AC type of clearance: micro-disconnection
- Industrial Relays - Dielectric strength pole - pole
- 2000 V AC type of insulation: basic
- Industrial Relays - Contact - Coil distance Clearance
- ≥ 3 mm
- Industrial Relays - Contact - Coil distance Creepage
- ≥ 4 mm
- Industrial Relays - Operating / release time (Typical)
- AC: 8 ms / 7 ms; DC: 10 ms / 3 ms
- Industrial Relays - Electrical life- resistive AC1
- greater than 2 x 10^5; 5 A. 250 V AC
- Industrial Relays - Mechanical life (cycles)
- greater than 2 x 10⁷
- Industrial Relays - Dimensions (L x W x H)
- 27.5 x 14 x 32.9 mm
- Industrial Relays - Weight
- 22 g
- Industrial Relays - Storage Temperature
- -40...+70 °C
- Industrial Relays - Operating Temperature
- -40...+55 °C
- Industrial Relays - Protection Category
- IP 40 PN-EN 60529
- Industrial Relays - Shock resistance (NO/NC)
- 10 g
- Industrial Relays - Vibration resistance
- 5 g 10...150 Hz
- Industrial Relays - Solder bath temperature
- max. 270 °C
- Industrial Relays - Soldering time
- max. 5 s
- Industrial Relays - Relay Type
- R2M
Datos del producto
- Marca
- Altech
- Número de parte
- R2M-2012-23-1012
- Categoría
- Relevadores de estado sólido
- Precio y entrega
- Por cotización
