PI6-1T-5...32VDC
SPST(1NO) DC Coil, Solid State Module RelayPI6-1T SPST(1NO) DC Coil, Solid State Module Relay Standard Features Width 6.2 mm PI6-1T - with triac output 35 mm rail mount Maybe linked with interconnection strip type ZG20 Equipped in green LED DATA Sheet Link
CantidadPrecio y entrega: Por cotización
¿Necesitas un equivalente u otra presentación? Llámanos al +52 (868) 817-7915 o escribe a ventas@gugo.com.mx.
Especificaciones técnicas
- Industrial Relays - Number and type of contacts
- SPST (1NO)
- Industrial Relays - Rated / max. switching voltage AC
- 400 V / 440 V
- Industrial Relays - Min. switching voltage
- 20 V
- Industrial Relays - Rated load (capacity) AC1
- 1.2 A / 400 V AC
- Industrial Relays - Min. switching current
- 10 mA
- Industrial Relays - Rated current
- 1.2A
- Industrial Relays - Rated power consumption
- DC: 0.3 W; 5...32 V DC at 24 V, AC/DC: 0.3 VA / 0.3 W; 24 V AC/DC and 1.6 VA / 1.6 W; 230 V AC/DC
- Industrial Relays - Insulation rated voltage
- 600 V AC
- Industrial Relays - Insulation pollution degree
- 2
- Industrial Relays - Operating time (typical value)
- 10 ms max. (zero turn-on)
- Industrial Relays - Release time (typical value)
- 10 ms max.
- Industrial Relays - Dimensions (L x W x H)
- 93.8 x 6.2 x 80 mm
- Industrial Relays - Weight
- 40 g
- Industrial Relays - Storage Temperature
- -40...+70 °C
- Industrial Relays - Operating Temperature
- -40...+55 °C
- Industrial Relays - Protection Category
- IP 20 PN-EN 60529
- Industrial Relays - Environmental Protection
- RTI PN-EN 116000-3
- Industrial Relays - Rated input voltage Un
- 5…32 V DC
- Industrial Relays - Power of input circuit
- 0.3 W at 24V
- Industrial Relays - Dielectric strength Input - output (type of insulation: reinforced)
- 4000 V AC 50/60 Hz. 1 min..
- Industrial Relays - Max. non-repeat surge current
- 30 A^2 t equals 20 ms
- Industrial Relays - I^2t for fusing
- 5.1 A2s t equals 1-10 ms
- Industrial Relays - dI/dt
- 50 A/μs
- Industrial Relays - dV/dt
- 40 V/μs
- Industrial Relays - Turn-off voltage
- AC: ≥ 0.2 Un; DC: ≥ 0.1 Un
- Industrial Relays - Relay Type
- PI6-1T
Datos del producto
- Marca
- Altech
- Número de parte
- PI6-1T-5...32VDC
- Categoría
- Relevadores de estado sólido
- Precio y entrega
- Por cotización
