8349005013
Unidad de control de 1 canal p sensores de superficie plana,Control Unit for KJR Series Ring Sensors The Control Unit can be operated with all KJR Series Ring Sensors. It allows evaluation of the sensor signals and at the same time it is its power supply. Standard Features DIN Rail Mount For Use with all KJR Series Ring Sensors 115V AC and 230V AC version Operation with 24VDC Transistor and Relay Output Adjustable Pulse Duration of Output Signal Output signal can be retriggered
CantidadPrecio y entrega: Por cotización
¿Necesitas un equivalente u otra presentación? Llámanos al +52 (868) 817-7915 o escribe a ventas@gugo.com.mx.
Especificaciones técnicas
- Metal Detection - Operating Temp.
- -10°C..+50°C
- Metal Detection - Protection Class
- IP20
- Metal Detection - Housing Material
- Polycarbonate (UL94V-0)
- Metal Detection - Supply Voltage
- 115 VAC (50/60Hz), 24 VDC
- Metal Detection - Sensor Supply
- 24 VDC, max. 80mA (Overload and Short Circuit Protected)
- Metal Detection - Transistor Output
- 1 x NPN, 1 x PNP, 25mA open collector
- Metal Detection - Relay Output
- 1 x SPDT, max. 250 VAC, 5A
- Metal Detection - Output Pulse Duration
- 1..10s/ 1..60s adjustable
- Metal Detection - Storage Temperature
- -10°C..+60°C
Datos del producto
- Marca
- Altech
- Número de parte
- 8349005013
- Línea
- Home
- Categoría
- Sensores
- Precio y entrega
- Por cotización
